Wahlberg DC motor controller https://wahlberg.dk/products/motors/dc-motor-controller  with this you control speed, position, direction

Lift vertical, Push horizontal

Linear Drive (end switches?)

 https://wahlberg.dk/products/motors/actuator-13-mms-300-kg?variant=267

An actuator is a component of a machine that is responsible for moving and controlling a mechanism or system, for example by opening a valve. In simple terms, it is a "mover". An actuator requires a control signal and a source of energy.

Power supply, PWM, Converter PWM, Safety circuit, Feedback Poti, End switches

Of Wahlberg actuators: speed:13 mm/sec - 48 mm/sec, stroke: 100 mm and 400 mm, weight: 20 kg – 300 kg (not all combinations possible)

Erdung (? Jonas?), a motor does not only consume power but also produce power so when turning it off there´s a voltage peak which goes into the circuit. that´s why it needs a safety circui

V1: Big Rotator (Lever) with turning power  supply, V2: DMX Motor Unit (Turning Stage), V3: DC Motor (Turning Stage)

V1 + V2: Ctrl integrated (OnOff, Position (??) Speed, Direction) V3: needs external DC motor controller ((OnOff, Position (??) Speed, Direction)

V4: simplest version (On/Off, Speed) needs Relais/PWM, Converter DMX-PWM, Power supply, safety circuit

V1: Working load limit - Shaft down: 150 kg, Rotation speed: 0,15-6,8 rp, Rotation limit:No limit / Continuous rotation V2: Motor speed: Slow: 5-65 RPM, Fast: 5-110 RPM
Torque: Slow: 4 Nm, Fast: 2 Nm
Drive shaft – Slow: Max Radial Load: 80 N, Max Axial Load: 15 N
Drive shaft - Fast: Max Radial Load: 40 N, Max Axial Load: 15 N, V3: Motor speed: 110 RPM Torque: 2 Nm (2kg/10 cm from center)

Direct: circular horizontal, indirect: linear hidden, with magnet fixt on axis)

https://zentralvertrieb.de/Ladeneinrichtung/Drehbuehnen/Drehbuehnen/Haengedrehbuehnen/Haengedrehbuehnen_1/Haengedrehbuehne-SWD-200-H-300/haengedrehbuehne-swd-200-h-300-schleifkontakt.html

integrated https://wahlberg.dk/products/dmx-winches/winch-10

A winch is a mechanical device that is used to pull in or let out or otherwise adjust the tension of a rope or wire rope. In its simplest form, it consists of a spool attached to a hand crank. Winches are the basis of such machines as tow trucks, steam shovels and elevators

integrated (OnOff, Position, Speed, Direction)

Lifting capacity:10 kg (with hoist >10 kg) , Lifting height:10 m, Lifting speed: 5-30 cm/s

direct: pulling lifting, indirect: grabbing…

always needs a counterweight

Conveyor belt as in industrial or we only use one part of the conveyor belt (the roll)

V1: dc motor + controller + preproduced conveyor belt) https://www.fedotec.de/en/conveyor-belts/fedotec-conveyor-belts/   V2:conveyor belt + dmx motor unit

V1: needs dc controller and connection, V2: controller integrated, mechanical connection needed

V4: simplest version (On/Off, Speed) needs Relais/PWM, Converter DMX-PWM, Power supply, safety circuit

Power supply, PWM, Converter PWM, Safety circuit, Feedback Poti, End switches

Continuous, horizontal movement

does not need a motor, but there´s different versions: simple magnet or theatre solution: Kabuki clamp: https://electrokabuki.com/configuration/

Quick release (gravitation or tension), quick impulse for anything

Permanent electromagnet is not magnetic when it gets power (electromagnets the other way around)

Abstoßung (geht auch mit E-Magneten)

An actuator is a component of a machine that is responsible for moving and controlling a mechanism or system, for example by opening a valve. In simple terms, it is a "mover". An actuator requires a control signal and a source of energy.

https://www.steinigke.de/de/licht/buehneneffekte/spezialeffekte/cat-s1080200-1.html

Explosive
